Type	Double Sided, Single Sided
Brand	Pix
Material	Rubber
Pitch	2 mm
Temperature Range	-25 deg C to +100 deg C
Section	2 M
Tooth Height	0.75 mm
Belt Thickness	1.36 mm
Manufacturing Range	52 2M to 750 2M
Length Designation	Lp

PIX is the world's leading manufacturer of Industrial Belts to suit wide array of applications.

The product range includes, but not limited to:
• Classical Timing Belts
• HTD Belts
• Std Belts

Features:
• High efficiency due to positive engagement between Belt teeth and pulley grooves
• Maintenance-free, no re-tensioning & high tension required
• Fibre glass cord provides strength, excellent flex life & high resistance to elongation
• Exact power transmission
• Low noise level & longer service life
• Improved stress distribution

Application:
• Suitable for drives demanding exact power transmission such as robotic machines, textile machinery, CNC machines, electronic equipment such as printers, scanners, currency counting machines etc.

Standard:
• BS 4548, ISO 13050, 5296, DIN 7721

Specifications:

Section	Pitch(mm)	Tooth Height 'b' (mm)	Belt Thickness 'c' (mm)	Manufacturing Range	Length Designation
S 3M	3	1.14	2.2	STD S 3M 120 to STD S 3M 6510	Lp
S 5M	5	1.91	3.4	STD S 5M 150 to STD S 5M 4000	Lp
S 8M	8	3.05	5.3	STD S 8M 376 to STD S 8M 6640	Lp
S 14M	14	5.3	10.2	STD S 14M 714 to STD S 14M 5012	Lp
